CAS Number128-69-8
SynonymsPerylo(3,4-cd:9,10-c'd')dipyran-1,3,8,10-tetrone; perylene-3,4:9,10-tetracarboxylic dianhydride; Pigment Red 224,PTCDA; Perylenetetracarboxydianhydride; MFCD00006916; 3,4,9,10-Perylenetetracarboxylic dianhydride; Peryleno[10,9-cd:3,4-c'd']dipyran-1,3,8,10-tetrone; Pigment Red 224; Red R-6418; Per acid; Isochromeno[4',5',6':6,5,10]anthra[2,1,9-def]isochromene-1,3,8,10-tetrone; Perylenetetracarboxylic dianhydride; EINECS 204-905-3; PTCDA; C.I.Pigment Red 224; perylene-3,4,9,10-tetracarboxylic acid dianhydride; 3,4,9,10-Perylenetet; Perylene-3,4,9,10-tetracarboxylic dianhydride; 3,4,9,10-perylene dianhydride; Perylo[3,4-cd:9,10-c'd']dipyran-1,3,8,10-tetrone
Molecular FormulaC24H8O6
Molecular Weight392.32
Purity97%
Density1.8±0.1 g/cm3
Boiling Point755.8±33.0 °C at 760 mmHg
Melting Point>300 °C
Appearancepowder
EINECS204-905-3
Symbol
Signal WordWarning
| Chemical & Physical Properties | |
|---|---|
| CAS Number | 128-69-8 |
| Catalog No. | 2A-9020618 |
| Chinese Name | 3,4,9,10-四羧酸酐 |
| Synonyms | Perylo(3,4-cd:9,10-c'd')dipyran-1,3,8,10-tetrone; perylene-3,4:9,10-tetracarboxylic dianhydride; Pigment Red 224,PTCDA; Perylenetetracarboxydianhydride; MFCD00006916; 3,4,9,10-Perylenetetracarboxylic dianhydride; Peryleno[10,9-cd:3,4-c'd']dipyran-1,3,8,10-tetrone; Pigment Red 224; Red R-6418; Per acid; Isochromeno[4',5',6':6,5,10]anthra[2,1,9-def]isochromene-1,3,8,10-tetrone; Perylenetetracarboxylic dianhydride; EINECS 204-905-3; PTCDA; C.I.Pigment Red 224; perylene-3,4,9,10-tetracarboxylic acid dianhydride; 3,4,9,10-Perylenetet; Perylene-3,4,9,10-tetracarboxylic dianhydride; 3,4,9,10-perylene dianhydride; Perylo[3,4-cd:9,10-c'd']dipyran-1,3,8,10-tetrone |
| Molecular Formula | C24H8O6 |
| Molecular Weight | 392.32 |
| Purity | 97 |
| Density | 1.8±0.1 g/cm3 |
| Boiling Point | 755.8±33.0 °C at 760 mmHg |
| Melting Point | >300 °C |
| Appearance | powder |
| Water Solubility | insoluble |
| Storage Condition | Packed in sacks or woven bags lined with plastic b |
| Application | PTCDA is an organic dye molecule and organic semiconductor [1]. |
| EINECS | 204-905-3 |
| HTC | 29173980 |
| PubChem ID | 24898155 |
| MDL Number | MFCD00006916 |
| SMILES | O1C(=O)c2c3c4c(c5c6c(c4cc2)ccc7c6c(cc5)C(=O)OC7=O)ccc3C1=O |
| InChI | 1S/C24H8O6/c25-21-13-5-1-9-10-2-6-15-20-16(24(28)30-23(15)27)8-4-12(18(10)20)11-3-7-14(22(26)29-21)19(13)17(9)11/h1-8H |
| InChI Key | CLYVDMAATCIVBF-UHFFFAOYSA-N |
| Beilstein/REAXYS | 57831 |
| NACRES Code | NA.23 |
| UNSPSC | 12352103 |
| Hazard Symbols | Transport |
| MSDS | msds/20618_1_128_69_8.pdf |
| Bioactivity | PTCDA is an organic dye molecule and an organic semiconductor[1]. Related Catalog Research Areas >> Others References [1]. F.S. Tautz, et al. Structure and bonding of large aromatic molecules on noble metal surfaces: The example of PTCDA. Progress in Surface Science. Volume 82, Issues 9-12, 2007, Pages 479-520. Chemical & Physical Properties Density 1.8±0.1 g/cm3 Boiling Point 755.8±33.0 °C at 760 mmHg Melting Point >300 °C(lit.) Molecular Formula C24H8O6 Molecular Weight 392.32 Flash Point 329.9±25.4 °C Exact Mass 392.032074 PSA 86.74000 LogP 3.01 Vapour Pressure 0.0±2.5 mmHg at 25°C Index of Refraction 1.973 InChIKey CLYVDMAATCIVBF-UHFFFAOYSA-N SMILES O=C1OC(=O)c2ccc3c4ccc5c6c(ccc(c7ccc1c2c73)c64)C(=O)OC5=O Water Solubility insoluble |
| Use of | PTCDA is an organic dye molecule and an organic semiconductor[1]. Properties Name 3,4,9,10-Perylenetetracarboxylic dianhydride Synonym More Synonyms Biological Activity Description PTCDA is an organic dye molecule and an organic semiconductor[1]. Related Catalog Research Areas >> Others References [1]. F.S. Tautz, et al. Structure and bonding of large aromatic molecules on noble metal surfaces: The example of PTCDA. Progress in Surface Science. Volume 82, Issues 9-12, 2007, Pages 479-520. Chemical & Physical Properties Molecular Formula C24H8O6 Exact Mass 392.032074 PSA 86.74000 Index of Refraction 1.973 InChIKey CLYVDMAATCIVBF-UHFFFAOYSA-N Water Solubility insoluble |
| Tax Rebate | 13.0% |
| Supervision | None. MFN tariff: 6.5%. Ordinary tariff: 20.0% |
| Transport Info | Shipping Name: UN |
| MSDS Transport Info | Module 14. Shipping information 14.1 UN dangerous goods number European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.2 United Nations shipping name European Land Transport Dangerous Regulations: Non-dangerous goods IMDG Code: Non-dangerous goods International air transport dangerous goods regulations: non-dangerous goods 14.3 Transport hazard categories European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.4 Package group European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.5 Environmental hazards European Land Transport Danger Regulations: No International Maritime Danger Regulations International Air Transport Danger Regulations: No Marine pollutants (yes/no): No 14.6 Special reminder to users No data available The above information is believed to be correct, but is not all-inclusive and should be used as a guide only. The information in this document is based on our current knowledge and is Correct safety instructions apply to this product. This information does not represent a warranty as to the properties of this product. See reverse side of invoice or packing slip. |
