CAS Number81-33-4
Synonymsperylene-3,4,9,10-tetracarboxylic acid diimide; Pigment Violet 29; perylene-3,4,9,10-tetracarboximide; perylene-3,4,9,10-tetracarboxylic diimide; C.I. Pigment Violet 29; 3,4,9,10-Perylenetetracarboxylic diimide; C.I.Pigment Brown 26; Einecs 201-344-6; PTCI; Perylimid; DINAPHTHALIMIDE; C.I.Pigment Purple 29; MFCD00024144; 3a,5a-Dihydroisoquinolino[4',5',6':6,5,10]anthra[2,1,9-def]isoquinoline-1,3,8,10(2H,9H)-tetrone
Molecular FormulaC24H10N2O4
Molecular Weight390.35
Purity98.00%
Density1.6±0.1 g/cm3
Boiling Point781.7±60.0 °C at 760 mmHg
AppearancePurple red powder
| Chemical & Physical Properties | |
|---|---|
| CAS Number | 81-33-4 |
| Catalog No. | 2A-9017344 |
| Chinese Name | 3,4,9,10－苝四甲酰二亚胺 |
| Synonyms | perylene-3,4,9,10-tetracarboxylic acid diimide; Pigment Violet 29; perylene-3,4,9,10-tetracarboximide; perylene-3,4,9,10-tetracarboxylic diimide; C.I. Pigment Violet 29; 3,4,9,10-Perylenetetracarboxylic diimide; C.I.Pigment Brown 26; Einecs 201-344-6; PTCI; Perylimid; DINAPHTHALIMIDE; C.I.Pigment Purple 29; MFCD00024144; 3a,5a-Dihydroisoquinolino[4',5',6':6,5,10]anthra[2,1,9-def]isoquinoline-1,3,8,10(2H,9H)-tetrone |
| Molecular Formula | C24H10N2O4 |
| Molecular Weight | 390.35 |
| Purity | 98.00 |
| Density | 1.6±0.1 g/cm3 |
| Boiling Point | 781.7±60.0 °C at 760 mmHg |
| Appearance | Purple red powder |
| Water Solubility | Water solubility: insoluble |
| Storage Condition | This product should be sealed and stored in a dry |
| Application | 3,4,9,10-Polyethylenetetracarboxylic diimine (PTCDI) is an organic heterocyclic compound and a dimethylimine that can be used as biological dyes and indicators [1]. |
| HTC | 2933499090 |
| MDL Number | MFCD00024144 |
| SMILES | [nH]1[c](c2c3c4c(c5c6c7c([c]([nH][c](c7cc5)=O)=O)ccc6c4cc2)ccc3[c]1=O)=O |
| InChI | 1S/C24H10N2O4/c27-21-13-5-1-9-10-2-6-15-20-16(24(30)26-23(15)29)8-4-12(18(10)20)11-3-7-14(22(28)25-21)19(13)17(9)11/h1-8H,(H,25,27,28)(H,26,29,30) |
| InChI Key | KJOLVZJFMDVPGB-UHFFFAOYSA-N |
| NACRES Code | NA.23 |
| UNSPSC | 12352302 |
| MSDS | msds/17344_1_81_33_4.pdf |
| Bioactivity | 3,4,9,10-Perylenetetracarboxylic-diimide (PTCDI), an organic heteropolycyclic compound, is a dimethylimine that can be used in biological dyes and indicators[1]. Related Catalog Research Areas >> Others Signaling Pathways >> Others >> Others References [1]. Tatsuya Yoshida, et al. Spectral Diffusion of Excitons in 3,4,9,10-Perylenetetracarboxylic-diimide (PTCDI) Thin Films. J Phys Chem B. 2021 Aug 19;125(32):9350-9356. Chemical & Physical Properties Density 1.6±0.1 g/cm3 Boiling Point 781.7±60.0 °C at 760 mmHg Molecular Formula C24H10N2O4 Molecular Weight 392.363 Flash Point 295.2±33.0 °C Exact Mass 392.079712 PSA 99.86000 LogP 0.38 Vapour Pressure 0.0±2.7 mmHg at 25°C Index of Refraction 1.802 InChIKey KJOLVZJFMDVPGB-UHFFFAOYSA-N SMILES O=C1NC(=O)c2ccc3c4ccc5c6c(ccc(c7ccc1c2c73)c64)C(=O)NC5=O |
| Use of | 3,4,9,10-Perylenetetracarboxylic-diimide (PTCDI), an organic heteropolycyclic compound, is a dimethylimine that can be used in biological dyes and indicators[1]. Properties Name perylenediimide Synonym More Synonyms Pigment Violet 29 Biological Activity Description 3,4,9,10-Perylenetetracarboxylic-diimide (PTCDI), an organic heteropolycyclic compound, is a dimethylimine that can be used in biological dyes and indicators[1]. Related Catalog Research Areas >> Others Signaling Pathways >> Others >> Others References [1]. Tatsuya Yoshida, et al. Spectral Diffusion of Excitons in 3,4,9,10-Perylenetetracarboxylic-diimide (PTCDI) Thin Films. J Phys Chem B. 2021 Aug 19;125(32):9350-9356. Chemical & Physical Properties Molecular Formula C24H10N2O4 Exact Mass 392.079712 PSA 99.86000 Index of Refraction 1.802 InChIKey KJOLVZJFMDVPGB-UHFFFAOYSA-N |
| Tax Rebate | 13.0% |
| Supervision | None. MFN tariff: 6.5%. Ordinary tariff: 20.0% |
| Transport Info | Product name: Purity: 0.0% |
| MSDS Transport Info | Module 14. Shipping information United Nations classification: inconsistent with United Nations classification standards UN number: not specified |
