CAS Number1662-01-7
Synonyms4,7-diphenyl[1,10]phenanthroline; bathophenanthrolin; 4,4'-diphenyl-1,10-phenantrolene; 4,7-Diphenyl-1,10-phenanthroline; Bathophen; 4,7-Diphenyl-1,10-phenanthroline,BPhen; BATHOPHENANTHROLINE R. G.; 1,10-bathophenanthroline; MFCD00004976; Bathophenantroline; 4,7-Diphenyl-1,10-Phenanthroline,(BathoPhenanthroline); EINECS 216-767-1; Bathophenanthroline; 3,4-Dimethoxybenzyl alcohol
Molecular FormulaC24H16N2
Molecular Weight332.40
Purity98.00%
Density1.2±0.1 g/cm3
Boiling Point543.1±50.0 °C at 760 mmHg
Melting Point218-220 °C(lit.)
Appearanceoff-white solid
Symbol
Signal WordWarning
| Chemical & Physical Properties | |
|---|---|
| CAS Number | 1662-01-7 |
| Catalog No. | 2A-9027220 |
| Chinese Name | 4,7-二苯基-1,10-菲咯啉 |
| Synonyms | 4,7-diphenyl[1,10]phenanthroline; bathophenanthrolin; 4,4'-diphenyl-1,10-phenantrolene; 4,7-Diphenyl-1,10-phenanthroline; Bathophen; 4,7-Diphenyl-1,10-phenanthroline,BPhen; BATHOPHENANTHROLINE R. G.; 1,10-bathophenanthroline; MFCD00004976; Bathophenantroline; 4,7-Diphenyl-1,10-Phenanthroline,(BathoPhenanthroline); EINECS 216-767-1; Bathophenanthroline; 3,4-Dimethoxybenzyl alcohol |
| Molecular Formula | C24H16N2 |
| Molecular Weight | 332.40 |
| Purity | 98.00 |
| Density | 1.2±0.1 g/cm3 |
| Boiling Point | 543.1±50.0 °C at 760 mmHg |
| Melting Point | 218-220 °C(lit.) |
| Appearance | off-white solid |
| Water Solubility | Water solubility: slightly soluble; soluble in: be |
| Storage Condition | Keep container sealed and store in a cool, dry pla |
| Application | Bafophenanthroline is a reagent that can be used to measure iron concentration in water, serum and urine samples by staining. |
| HTC | 29339990 |
| PubChem ID | 329749373 |
| SMILES | c1ccc(-c2ccnc3c2ccc2c(-c4ccccc4)ccnc23)cc1 |
| InChI | InChI=1S/C24H16N2/c1-3-7-17(8-4-1)19-13-15-25-23-21(19)11-12-22-20(14-16-26-24(22)23)18-9-5-2-6-10-18/h1-16H |
| InChI Key | DHDHJYNTEFLIHY-UHFFFAOYSA-N |
| Hazard Symbols | transportation |
| Bioactivity | Bathophenanthroline is an agent used for the measurement of iron concentrations in aqueous , serum and urine samples by colorimetry. Related Catalog Signaling Pathways >> Others >> Others Research Areas >> Others Dye Reagents Chemical & Physical Properties Density 1.2±0.1 g/cm3 Boiling Point 543.1±50.0 °C at 760 mmHg Melting Point 218-220 °C(lit.) Molecular Formula C24H16N2 Molecular Weight 332.397 Flash Point 242.1±21.4 °C Exact Mass 332.131348 PSA 25.78000 LogP 5.51 Vapour Pressure 0.0±1.4 mmHg at 25°C Index of Refraction 1.710 InChIKey DHDHJYNTEFLIHY-UHFFFAOYSA-N SMILES c1ccc(-c2ccnc3c2ccc2c(-c4ccccc4)ccnc23)cc1 Stability Stable. Incompatible with strong oxidizing agents. |
| Use of | Bathophenanthroline is an agent used for the measurement of iron concentrations in aqueous , serum and urine samples by colorimetry. Properties Articles49 Name 4,7-diphenyl-1,10-phenanthroline Synonym More Synonyms Bathophenanthroline Biological Activity Description Bathophenanthroline is an agent used for the measurement of iron concentrations in aqueous , serum and urine samples by colorimetry. Related Catalog Signaling Pathways >> Others >> Others Research Areas >> Others Dye Reagents Chemical & Physical Properties Molecular Formula C24H16N2 Exact Mass 332.131348 PSA 25.78000 Index of Refraction 1.710 InChIKey DHDHJYNTEFLIHY-UHFFFAOYSA-N Stability Stable. Incompatible with strong oxidizing agents. |
| Tax Rebate | 13.0% |
| Supervision | None. MFN tariff: 6.5%. Ordinary tariff: 20.0% |
| Transport Info | Product name: Purity: 99.0% |
| MSDS Transport Info | Module 14. Shipping information 14.1 UN dangerous goods number European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.2 Names specified by the United Nations (UN) European Land Transport Dangerous Regulations: Non-dangerous goods IMDG Code: Non-dangerous goods International air transport dangerous goods regulations: non-dangerous goods 14.3 Transport hazard categories European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.4 Package group European Land Transport Dangerous Regulations: -International Maritime Dangerous Regulations: -International Air Transport Dangerous Regulations: - 14.5 Environmental hazards European Land Transport Dangerous Regulations: No International Maritime Transport Dangerous Regulations Maritime Pollutants: No International Air Transport Risk Regulations: No 14.6 Special reminder to users No data available |
